Technical details Supported Operating Systems Operating system Windows 11 Home 64/office 2007 Processor Chipset AMD A78 FCH Processor family AMD Quad-Core A-Series processor Processor AMD Quad-Core A10-8750 APU with Radeon™ R7 Graphics (3.6 GHz, up to 4 GHz, 4 MB cache) Memory Memory 8 GB Memory Memory Slots 2 DIMM Maximum Memory Upgradeable to 16 GB Drives Internal Storage 2 TB 7200 rpm SATA 120GB SSD Optical drive Ultra Slim SuperMulti DVD burner Graphic Subsystem Graphics AMD Radeon R7 Graphics Graphics NVIDIA GeForce GT 730 (2 GB ) Graphics Discrete Graphics Integrated HP Pavilion 550-114a Desktop PC Product Specifications(Refurbished) Motherboard Orchid3 Figure : The Orchid3 motherboard Manufacturer: Foxconn Form factor: uATX: 24×24 cm (9.4×9.4 in) Chipset: FCH (A78) Memory sockets: 2 x DDR3 Processor socket: FM2b Expansion Slots: 1 PCI Express x16 (Gen 3.0) 1 PCI Express x1 (Gen 2.0) Half-length mini card with WLAN header For more details, see Orchid3 motherboard specifications. Processor AMD A10 8750 CPU speed: up to 3.6 GHz CPU cores: 4 CPU Cache: 4 MB TDP: 65 W Socket: FM2b Processor upgrade information up to 95 W Socket type: FM2b Motherboard supports the following processor upgrades: Processor TDP Integrated Graphics AMD A10 8850 (Godavari) 3.9 GHz Quad Core 95 W Radeon R7 Series AMD A10 8750 (Godavari) 3.6 GHz Quad Core 65 W (cTDP – 45 W) Radeon R7 Series AMD A8-8650 (Godavari) 3.2 GHz Quad Core 65 W (cTDP – 45 W) Radeon R7 Series AMD A6-8550 (Godavari) 3.7 GHz Dual Core 65 W (cTDP – 45 W) Radeon R5 Series AMD A10-7800 (Kaveri) 3.5 GHz Quad Core 65 W (cTDP – 45 W) Radeon R7 Series AMD A8-7600 (Kaveri) 3.1 GHz Quad Core 65 W (cTDP – 45 W) Radeon R7 Series AMD A4-7300 (Kaveri) 3.8 GHz Dual Core 65 W (cTDP – 45 W) Radeon HD 8470D Memory 8 GB Amount: 8 GB Speed: PC3-12800 MB/s Type: DDR3-1600 Memory upgrade information Quad channel memory architecture Two DDR3 DIMM (240-pin) sockets Supports DDR3 DIMMs PC3-14400 (DDR3-1866) PC3-12800 (DDR3-1600) PC3-10600 (DDR3-1333) Supports 1 GB, 2 GB, 4 GB or 8 GB DIMMs Supports up to 4 GB on 32-bit systems NOTE: 32-bit systems cannot address a full 4.0 GB of memory. Supports up to 16 GB on 64-bit systems NOTE: Maximum memory shown reflects the capability of the hardware and can be limited further in the operating system. Video Graphics NVIDIA GeForce GT 730 (Aries M1 – 2 GB) Figure : Video card Figure : Video card ports HDMI DVI-I Form factor: Low profile PCB with ATX Dimensions: 6.9×14.5 cm (2.7×5.7 in) Maximum resolution: HDMI resolution: 1920 x 1080 @ 60 Hz (HDMI 1.4) DVI resolution: 2560 x 1600 x 32bpp @ 60Hz (Dual Link) Analog VGA resolution: 2048 x 1536 x 32bpp @ 60Hz (through DVI2VGA dongle) 4 GB onboard memory Memory type: 256M x 16 DDR3 (Micron/Hynix) @ 8pcs Supports Blu-ray Total power consumption: <35 W max Supports up to 2 displays at the same time Integrated graphics AMD Radeon Integrated Graphics Specific graphics depend on the processor. See the processor upgrade information section for more information. NOTE: Integrated graphics does not work if a graphics card is installed Sound/audio Integrated audio Audio codec: ALC659-CG Audio jack sensing Integrated 5.1 channel support Networking Integrated Bluetooth 4.0 and Wireless LAN 802.11b/g/n featuring Single-band (2.4Ghz) 1 x 1 technology Figure : Top view of the WLAN card Form factor: PCI express half-length mini card Wireless standard: 802.11 b/g/n Bluetooth support: Bluetooth 4.0 Data rates: 802.11b: 1, 2, 5.5, 11 Mbps 802.11g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps 802.11n: card will support rates for NSS=1 for RX and TX for 20 MHz channels. Short and long guard interval shall be supported. Antennas: 2 embedded single band 2.4 antennas o Supported security protocols: IEEE and WiFi compliant 64 / 128 bit WEP encryption for a/b/g mode only AES-CCMP: 128 bit in hardware 802.1x authentication WPA, WPA2: 802.1x. WPA-PSK, WPA2-PSK, TKIP, and AES WPA2 certification IEEE 802.11i Cisco Certified Extensions, all versions through V5 WAPI LAN: 1000BASE-T: Technology: Realtek RTL8161 Data transfer speeds: up to 10/100/1000 Mb/s Transmission standards: 1000BASE-T Ethernet Hard Drive 2 TB Size: 2 TB Interface: SATA Rotational Speed: 7200 RPM CD/DVD Disc Drive Ultra Slim Tray SuperMulti DVD Burner drive Data transfer rates up to 3,600 KB/s (CD read/write) Data transfer rates up to 10,800 KB/s (DVD read/write) Formats/Disc types Write speeds Read speeds DVD DVD-ROM SL NA up to 8x DVD-ROM DL NA up to 8x DVD R SL up to 8x up to 8x DVD R DL up to 6x up to 8x DVD-R SL up to 8x up to 8x DVD-R DL up to 6x up to 8x DVD RW up to 8x up to 8x DVD-RW up to 6x up to 8x DVD-RAM up to 5x up to 5x CD CD-R up to 24x up to 24x CD-RW up to 10x up to 24x CD-ROM NA up to 24x Memory Card Reader 7-in-1 multimedia card reader Figure : View of memory card reader Supports the following cards: Secure Digital™ (SD) Secure Digital High Capacity (SDHC) SDXC Memory Stick Memory Stick Select Memory Stick PRO Memory Stick MagicGate Computer Case Chassis Height: 36.39 cm (14.33 in) Width: 16.51 cm (6.50 in) Depth: 37.50 cm (14.88 in) Weight 7.15 kg (15.77 lbs) – without packaging Power Supply Internal 180 W PSU 180 W uATX aPFC internal power supply I/O Ports Front I/O ports USB 3.0: 2 Headphone: 1 Microphone: 1 Back I/O ports Figure : Orchid3 back I/O panel USB 2.0: 4 VGA HDMI USB 3.0: 2 LAN (Ethernet) Audio: Line in Audio: Line out Audio: Microphone Software Titles That Shipped with PC NOTE: HP provides basic support for software that comes with the computer. For in-depth feature assistance, refer to the help section in the software or on the software vendor’s Web site. Software Category Software Title Recovery Manager: Program Reinstallation Operating System Microsoft Windows 10 Home (64-bit) No Entertainment, Music & Games Bang & Olufsen Play CyberLink Power Media Player Hearts Deluxe (not available on all models) HP Games Netflix Priceline Simple Solitaire Trip Advisor No Yes No No No No No No Productivity Dropbox Evernote Intel WiDi Remote Microsoft Office Trial (online activation required) Snapfish The Weather Channel No Yes Yes No No No Imaging, Photography, Video & Film CyberLink Photo Director Yes Connected with HP HP Connected Drive No Security McAfee Checkbox McAfee LiveSafe (30-day subscription) No No Support HP PC Hardware Diagnostics UEFI HP Support Assistant Windows 10 Welcome App Yes Yes Yes Recovery HP TDC Recovery Solution No Browser Microsoft Edge No
