HP Pavilion 24-b013a 23.8-inch All-in-One Desktop PC (Turbo Silver) Specifications AMD A6-9630P 2.6GHZ Processor (2M Cache, upto 2.6 GHz) 16GB DDR4-2133 1TB SSD Hard Drive Ultra Slim Tray SuperMulti DVD Burner drive 60.45 cm (23.8 in) diagonal widescreen full high-definition IPS WLED-backlit edge-to-edge display (1920 x 1080) WITH TOUCH Integrated Radeon R5 Series Graphics Integrated Audio Realtek ALC3252 with Integrated speakers Integrated webcam with microphone 3-in-1 Memory card reader Integrated 1000BASE-T Gigabit Ethernet LAN Integrated Bluetooth 4.0 and Wireless LAN 802.11a/b/g/n/ac featuring Dual-band (2.4 GHz and 5.0 GHz) 1 x 1 technology 2 x USB 2.0 ports, 2 x USB 3.0 ports, 1 x USB-C, 1 x Headphone/Microphone combo, 1 x HDMI, 1 x LAN Wireless Keyboard & mouse, AC Adaptor & Power Cord included Microsoft Windows 10 Home High End (64-bit) HP Pavilion All-in-One – 24-b013a (ENERGY STAR) PC Product Specifications Product Release Information Display 60.45 cm (23.8 in) diagonal widescreen full high-definition IPS WLED-backlit edge-to-edge display (1920 x 1080) Size: 60.45 cm (23.8 in) diagonal Display resolution: 1920 x 1080 Motherboard Phuket-A10 Figure : The Phuket-A10 motherboard Form factor: Customized: 27.5×18.1 cm (10.8×7.1 in) Chipset: SoC configuration; processor and chipset are combined Memory sockets: 2 x DDR4 Expansion Slots: One M.2 slot for WLAN For more details, see Phuket-A10 motherboard specifications. Processor AMD A10-9630P CPU speed: 2.6 GHz (3.3 GHz max turbo boost) CPU cores: 4 CPU Cache: 2 MB L2 TDP: 35 W (cTDP 25/45 W) Integrated graphics: Radeon R5 Series Processor upgrade information Supports the AMD A10-9630P (Bristol Ridge) Quad Core processor only. Memory 16 GB Amount: 16 GB Speed: PC4-17000 MB/s Type: DDR4-2133 Memory upgrade information Dual channel memory architecture Two DDR4 SODIMM (260-pin) sockets Supports up to PC4-17000 (DDR4-2133) Supports 2 GB, 4 GB, and 8 GB DDR4 SODIMMs Supports up to 4 GB on 32-bit systems NOTE: 32-bit systems cannot address a full 4.0 GB of memory. Supports up to 16 GB (unbuffered) on 64-bit systems NOTE: Maximum memory shown reflects the capability of the hardware and can be limited further in the operating system. Video Graphics Integrated graphics Integrated Radeon R5 Series Graphics Sound/Audio Integrated audio Audio Codec: Realtek ALC3252 Audio jack presence detection Speakers Integrated speakers Networking Integrated Bluetooth 4.0 and Wireless LAN 802.11a/b/g/n/ac featuring Dual-band (2.4 GHz and 5.0 GHz) 1 x 1 technology Interface: M.2 Transmission standards: 802.11 a/ b/g/n/ac Dual band: 2.4 GHz and 5.0 GHz LAN: 1000BASE-T Technology: Realtek RTL8161GSH Data transfer speeds: up to 10/100/1000 Mb/s Transmission standards: 1000BASE-T Gigabit Ethernet Hard Drive ITB SSD Size: 1 TB Interface: SSD Rotational Speed: 7200 RPM CD/DVD Disc Drive Ultra Slim Tray SuperMulti DVD Burner drive Data transfer rates up to 3,600 KB/s (CD read/write) Data transfer rates up to 10,800 KB/s (DVD read/write) Formats/Disc types Write speeds Read speeds DVD DVD-ROM SL N/A up to 8x DVD-ROM DL N/A up to 8x DVD R SL up to 8x up to 8x DVD R DL up to 6x up to 8x DVD-R SL up to 8x up to 8x DVD-R DL up to 6x up to 8x DVD RW up to 8x up to 8x DVD-RW up to 6x up to 8x DVD-RAM up to 5x up to 5x CD CD-R up to 24x up to 24x CD-RW up to 10x up to 24x CD-ROM N/A up to 24x Memory Card Reader 3-in-1 Memory card reader Figure : View of memory card reader Supports the following cards: Secure Digital (SD) Secure Digital High Capacity (SDHC) SDXC Computer Case All-in-One Height: 44.7 cm (17.6 in) Width: 57.9 cm (22.8 in) Depth: 19.1 cm (7.5 in) Weight: 8.43 kg (18.59 lbs) unpackaged Front of the system Back of the system Left side of the system Figure : Left side of the system Right side of system Power Supply External 120 W Total wattage: 120 W Output voltage: 19.5 V I/O Ports Back I/O ports Bottom I/O ports Keyboard, Mouse and Input Devices Wireless keyboard Wireless technology: Two-way radio frequency Batteries: 2 AAA alkaline batteries Battery life: 10 months (typical) Dimensions (approximate): Height: 26.5 mm (1.0 in) Width: 133.0 mm (5.2 in) Length: 380.2 mm (15.0 in) Special keys: Mute Volume Up Volume Down Wireless mouse Wireless technology: Two-way 2.4GHz Radio Frequency Batteries: 2 AA alkaline Battery life: 6-12 months (typical) Buttons: 2 primary buttons Clickable scroll wheel Dimensions (approximate): Length: 114.8 mm (4.5 in) Width: 63.4 mm (2.5 in) Height: 37.2 mm (1.5 in) HP TrueVision HD Camera Software Titles That Shipped with PC NOTE: HP provides basic support for software that comes with the computer. For in-depth feature assistance, refer to the help section in the software or on the software vendor’s Web site. Software Category Software Title Recovery Manager: Program Reinstallation Operating System Microsoft Windows 11 Home High End (64-bit) No Entertainment, Music & Games Amazon B&O Play Booking.com CyberLink Power Media Player HP Games Netflix Simple Solitaire Trip Advisor No No No Yes No No No No Productivity Dropbox Snapfish No No Imaging, Photography, Video & Film CyberLink PowerDirector Yes Security McAfee LiveSafe (30-day subscription) No Support HP Documentation HP PC Hardware Diagnostics UEFI HP Support Assistant HP Welcome Yes Yes Yes No Recovery HP Recovery Manager No Browser Microsoft Edge No Standard warranty Terms & Conditions To initiate a claim, the Customer must notify the Seller In the event of Damage to Goods – Photographic evidence of packaging and damage must be provided within 24 hours of the Goods being delivered.
